Hot sales high quality UVA LEDs cob 1616 100W 365/385/395nm uva
60-90DEG uva leds chips for high power curing
365nm chip Product specification
| UV-A | POWER | Warranty | Dominant Wavelength | Optical Power | IF | VF | Circuit | WHOLE SIZE | Lighting Area | VIEW ANGLE | LENS | SUBSTRATE |
| LN-CVS16UV-P42 | 100W | 10,000Hrs
or 2 years | 365nm | 33500-38000mW | 2100mA
(Max=3A) | 48-54V | 14S3P | 16*16MM | R15MM | 60-90° | QUARTZ GLASS LENS | ALN Coppering |
| 385nm | 40000-48000mW |
| 395nm | 42000-50000mW |
1616 uva led chip Design Advantage
- Long life span
- low thermal resistance
- High effiency 40%-50%
- Ingorganic encapsulation
- High density and intensity
- Screw free assemble for high power curing use
uv led Appilcation
- UV curing
- LED growing market
- Offset printer
- 3D printer
- Exposure machines
- Inkjet printer
Company Profile
uva led chip FAQ
1: Do you supply OEM,ODM service?
A1: YES,absolutely it can be realized.Learnew focus on OEM & ODM
service more than 7 years.
Q2:All the pictures are real photo?
A2: Yes, the pictures of all products on this page are 100% real
shoot by us.
Q3: How can I get a quotation from you?
A3: Please kindly leave us messages about your needs,including
products parameters,application, you contact way and quantity,our
professional team will reply you in one hour here.
Q4: Is there any discount for bulk order?
A4: Yes, if you need bulk order or you want customized products, we
can provide wholesale price. Be our fans on alibaba or add learnew
opto to “my favorite stores”, you will always get our discount and
coupon information at the first time.
Q5: Do you support drop shipping and how much is the shipping cost?
A5: Yes, we support drop shipping. You should leave the receiver's
information when you place the order, then we will send the goods
according the address you have left. The shipping cost are based on
your order's volume and weight, you can check on alibaba or ask our
team.
Q6: How to place an order? A6: You can check the shipping cost and
discount
information online, and place order directly on Alibaba. Or you can
contact us for the order details, we will reply you in mins.
Q7: What payment terms are available?
A7: T/T,PayPal, Western Union and Secure Payment.
Q8: What about the lead time?
A8: It depends on the order quantity. In general, lead time is
about 10-15 working days. For samples in standard, the delivery
