The only factory 10 years concentrate on LED chip and LED light R&D and Manufacture.
5 Years
| Ask Lasest Price | |
| Brand Name : | Learnew |
| Model Number : | LN-CP-300 |
| Certification : | CE RoHs ISO SGS |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T, Western Union,Paypal |
| Supply Ability : | 1000pcs/month |
| Delivery Time : | 4-8 week days |
Curing Uv Led System Long Lifespan Low Thermal Resistance Inorganic Package 600W For Offset Printing Machine
500W UVA LED Systems specifications
| POWER | Dominant Wavelength | Optical Intensity | Recommend Radiation distance | Control method | Signal Port Voltage | VF | Power adjustment | DIMENSION | Lighting Area | VIEW ANGLE | LENS | CHIPS |
| 1200w(Max) | 395nm | >12w/cm2 | 3-10mm | Switching signal Dimming 0-1200W | 0-12V | AC220V | 10-100% | 310mm(L)*48mm (W)*68mm(H) | 300mm*20mm | 120° | QUARTZ GLASS LENS | High power SMD or COB |
| 600w(Max) | >12w/cm2 | Switching signal Dimming 0-600W | 160mm(L)*48mm (W)*68mm(H) | 150mm*20mm |
UVA LED Systems Advantages
1,Long life span
2,low thermal resistance
3,High effiency 45%-55%
4,Ingorganic encapsulation
5,High density and intensity
6,Screw free assemble for high power curing use
7,Multi wavelength 365nm/385nm/395nm/405nm/420nm in one design
8,Optical optimal with special view angle in 30DEG, 60DEG or 120DEG
600W 1200W UVA LED Systems Application
1,UV curing
2,LED growing market
3,Offset printer
4,3D printer
5,Exposure machines
6,Inkjet printer
7,High intensity curing Market like 3KW,7kW,15KW...
UVA Systems 600W 1200W Pictures
UV LED curing system FAQ:
Q1: Do you supply OEM,ODM service?
A1: YES,absolutely it can be realized.Learnew focus on OEM & ODM
service more than 7 years.
Q2:All the pictures are real photo?
|
|
